Rapid and Quantitative Detection of Cypermethrin in Spinach Based on Surface-Enhanced Raman Spectroscopy Combined with Deep Learning Model

doi:10.19894/j.issn.1000-0518.250115

Chinese Journal of Applied Chemistry ›› 2025, Vol. 42 ›› Issue (11): 1510-1523.DOI: 10.19894/j.issn.1000-0518.250115

• Full Papers • Previous Articles Next Articles

Rapid and Quantitative Detection of Cypermethrin in Spinach Based on Surface-Enhanced Raman Spectroscopy Combined with Deep Learning Model

Xiu-Xiu WU¹, Zhi-Min LIU¹, Dong YANG¹, Shun MAO¹, Yan-Xin WANG¹, De-Hua GUO²(), Fei XU¹()

^1.School of Health Science and Engineering，Shanghai Engineering Research Center of Food Rapid Detection，University of Shanghai for Science and Technology，Shanghai 200093，China
^2.Technical Center for Animal Plant and Food Inspection and Quarantine of Shanghai Customs，Shanghai 200135，China

Received:2025-03-15 Accepted:2025-06-16 Published:2025-11-01 Online:2025-12-05
Contact: De-Hua GUO,Fei XU
About author:xufei8135@126.com
guodehua@customs.gov.cn
Supported by:
Program of Shanghai Artificial Intelligence to Promote the Reform of Scientific Research Paradigm Enabling Discipline Leaping Plan(Z-2025-312-023)

Abstract

Abstract:

The residues of pyrethroid pesticides in vegetables and fruits can cause harm to human health. In this work， a surface-enhanced Raman spectroscopy （SERS） coupled with back propagation （BP） neural network deep learning model was established for rapid detection of cypermethrin （CPM） in spinach. Concretely， Ag/ZnO were applied as SERS substrates. Then， the collected SERS spectra were expanded， and the expanded spectral data were preprocessed by Savitzky-Golay （S-G）， mean centralization （MC） and the combination of the two methods. Furthermore， BP neural network models were established for the prediction of CPM in actual samples for the original enhanced spectrum and the pretreated spectrum， respectively， and three traditional machine learning models were established for comparison. It was found that the BP model has the best prediction performance based on the original expanded spectrum， with the prediction set R_P=0.9902， the root mean square error RMSEP=0.102 and the limit of detection 20 μg/L. The two-tailed paired t-tests showed that there was no significant difference between the standard method LC-MS and this method. The detection can be finished in 5~10 min. This work established an Ag/ZnO-based SERS method coupled with BP neural network model for the rapid and quantitative detection of CPM residues in spinach.

Key words: Cypermethrin, Spinach, Surface-enhanced Raman spectroscopy, Deep learning, Back propagation neural network

CLC Number:

O655.9

Xiu-Xiu WU, Zhi-Min LIU, Dong YANG, Shun MAO, Yan-Xin WANG, De-Hua GUO, Fei XU. Rapid and Quantitative Detection of Cypermethrin in Spinach Based on Surface-Enhanced Raman Spectroscopy Combined with Deep Learning Model[J]. Chinese Journal of Applied Chemistry, 2025, 42(11): 1510-1523.

Figures/Tables 11

References 38

[1]	GOURGOUTA M， RUMBOS C I， ATHANASSIOU C G. Residual toxicity of a commercial cypermethrin formulation on grains against four major storage beetles［J］. J Stored Prod Res， 2019， 83： 103-109.
[2]	SUN X， ZHAO Y， LIU L， et al. Visual whole-process monitoring of pesticide residues： an environmental perspective using surface-enhanced Raman spectroscopy with dynamic borohydride-reduced silver nanoparticles［J］. J Hazard Mater， 2024， 465： 133338 .
[3]	YAO T， LIU A， LIU Y， et al. Ratiometric fluorescence sensor for organophosphorus pesticide detection based on opposite responses of two fluorescence reagents to MnO［J］. Biosens Bioelectron， 2019， 145： 111705.
[4]	WU X， HUANG L， YANG Q， et al. Effective extraction of pyrethroid pesticides from cabbages using Fe₃O₄@NU-1000 and adsorption mechanism： an experimental and theoretical study［J］. Microchem J， 2024， 204： 110979.
[5]	JIAO T， HASSAN M M， ZHU J， et al. Quantification of deltamethrin residues in wheat by Ag@ZnO NFs-based surface-enhanced Raman spectroscopy coupling chemometric models［J］. Food Chem， 2020， 337： 127652.
[6]	EL-SHEIKH E S A， LI D， HAMED I， et al. Residue analysis and risk exposure assessment of multiple pesticides in tomato and strawberry and their products from markets［J］. Foods， 2023， 12（10）： 1936.
[7]	FERREIRA A Q， SONIA C N. Multiresidue method for determination of pesticides in coconut （Cocos nucifera Linn.） endosperm by using GC-MS/MS and UHPLC-MS/MS analysis［J］. J Food Composition Anal， 2021， 97（1）： 103764.
[8]	LI H， SHENG W， HASSAN M M， et al. Quantification of antibiotics in food by octahedral gold-silver nanocages-based SERS sensor coupling multivariate calibration［J］. Spectrochimica Acta Part A： Mol Biomol Spectrosc， 2024， 320： 124595.
[9]	ADADE S Y S S， LIN H， HARUNA S A， et al. SERS-based sensor coupled with multivariate models for rapid detection of palm oil adulteration with Sudan II and IV dyes［J］. J Food Compos Anal， 2022， 114： 104834.
[10]	ALAWADHI H， ALNAQBI M A， RAMACHANDRAN K， et al. Trace-level sensing of food toxins by flexible and cost-effective SERS sensors fabricated by pulsed-laser-deposition of gold nanoparticles on polycarbonate matrix［J］. Surf Interfaces， 2023， 40： 103016.
[11]	BARVEEN Y H L， WANG T， CHANG Y， et al. Ultrasensitive and reusable SERS probe for the detection of synthetic dyes in food industry through hybrid flower-shaped ZnO@Ag nanostructures［J］. J Alloys Compd， 2021， 861（1）： 157952.
[12]	CHUESIANG P， RYU V， SIRIPATRAWAN U， et al. Aptamer-based surface enhanced Raman spectroscopy （SERS） for the rapid detection of Salmonella Enteritidis contaminated in ground beef［J］. Food Sci Technol， 2021（150）： 111937.
[13]	XU L， XIE Y， LIN J， et al. Advancements in SERS-based biological detection and its application and perspectives in pancreatic cancer［J］. View， 2023， 5（1）： 20230070.
[14]	WANG S， PAN R， HE W， et al. In situ surface-enhanced Raman scattering detection of biomolecules in the deep ocean［J］. Appl Surf Sci， 2023， 620： 156854.
[15]	QIN C， ZHANG D， WU Z， et al. Construction of an efficient molecular enrichment and magnetic separation flow with Fe₃O₄@Ag@COF for ratiometric SERS detection of methamidophos［J］. Chem Eng J， 2024， 496： 154177.
[16]	LAI H， DAI H， LI G， et al. Rapid determination of pesticide residues in fruit and vegetable using Au@AgNPs decorated 2D Ni-MOF nanosheets as efficient surface-enhanced Raman scattering substrate［J］. Sens Actuators B， 2022， 369： 132360.
[17]	MA L， HAN E， YIN L， et al. Simultaneous detection of mixed pesticide residues based on portable Raman spectrometer and Au@Ag nanoparticles SERS substrate［J］. Food Control， 2023， 153： 109951.
[18]	LIU X， PANT U， LOGAN N， et al. Non-linear responses via agglomeration and aggregation of gold nanoparticles for surface-enhanced Raman spectroscopy （SERS） coupled with chemometric analysis for chlorpyrifos detection［J］. Food Chem， 2024， 455： 139944.
[19]	LEE S， ZHAO Q， LEE S， et al. Two-and three-dimensional Ag-Au nanoalloying： heterogeneous building blocks enhancing near-field focusing［J］. ACS Nano， 2024， 18（43）： 29880-29890.
[20]	GU Y， LI Y， QIU H， et al. Recent progress on noble-free substrates for surface-enhanced Raman spectroscopy analysis［J］. Coord Chem Rev， 2023， 497： 215425 .
[21]	LI H， GENG W， HASSAN M， et al. Rapid detection of chloramphenicol in food using SERS flexible sensor coupled artificial intelligent tools［J］. Food Control， 2021， 128（1）： 108186.
[22]	HAJIKHANI M， HEGDE A， SNYDER J， et al. Integrating transformer-based machine learning with SERS technology for the analysis of hazardous pesticides in spinach［J］. J Hazard Mater， 2024， 470： 134208.
[23]	ZHAO Z P， LI Q F， ZHANG Z X， et al. Combining a parallel 2D CNN with a self-attention Dilated Residual Network for CTC-based discrete speech emotion recognition［J］. Neural Networks， 2021， 141： 52-60.
[24]	DENG Y， XIAO H， XU J， et al. Prediction model of PSO-BP neural network on coliform amount in special food［J］. Saudi J Biol Sci， 2019， 26（6）： 1154-1160.
[25]	XING W， LIU X， XU C， et al. Application of artificial neural network to predict benzo［a］pyrene based on multiple quality of smoked sausage［J］. Food Sci Technol， 2022， 163： 113571.
[26]	WU X， YAN H， CAO Y， et al. Prediction acrylamide contents in fried dough twist based on the application of artificial neural network［J］. Food Chem： X， 2024， 24： 102007.
[27]	HUANG X， YOU Y， ZENG X， et al. Back propagation artificial neural network （BP-ANN） for prediction of the quality of gamma-irradiated smoked bacon［J］. Food Chem， 2024， 437： 137806.
[28]	JIAO T， KUTSANEDZIE F， XU J， et al. SERS-signal optimised AgNPs-plated-ZnO nanoflower-like structure synthesised for sensing applications［J］. Phys Lett A， 2019， 383（12）： 1312-1317.
[29]	ZHU J， JIANG X， RONG Y， et al. Label-free detection of trace level zearalenone in corn oil by surface-enhanced Raman spectroscopy （SERS） coupled with deep learning models［J］. Food Chem， 2023， 414： 135705.
[30]	HAO T， ZHAO L， WANG D， et al. The OED-BO-RFR model for predicting CBM pressure during the pre-drainage process［J］. Geomat Nat Haz Risk， 2024， 15（1）： 2399924.
[31]	ZHAO G， PAN X， YAN H， et al. Predicting engineering properties of controlled low-strength material made from waste soil using optimized SVR models［J］. Case Stud Constr Mater， 2024， 20： e03325.
[32]	LI W， LU B T， CHEN F F， et al. Host-guest complex of cypermethrin with β-cyclodextrin： a spectroscopy and theoretical investigation［J］. J Mol Struct， 2011， 990（1/2/3）： 244-252.
[33]	CHEN X， LIU L， KUANG H， et al. A strip-based immunoassay for rapid determination of fenpropathrin［J］. Anal Methods， 2013， 5（21）： 6234-6239.
[34]	ZHU J， YIN X， ZHANG W， et al. Simultaneous and sensitive detection of three pesticides using a functional poly（sulfobetaine methacrylate）-coated paper-based colorimetric sensor［J］. Biosensors， 2023， 13（3）： 309.
[35]	HUANG L， ZHANG F， LI F， et al. Development of Ic-ELISA and colloidal gold lateral flow immunoassay for the determination of cypermethrin in agricultural samples［J］. Biosensors， 2022， 12（11）： 1058.
[36]	YAO J， XU X， LIU L， et al. Gold nanoparticle-based immunoassay for the detection of bifenthrin in vegetables［J］. Food Addit Contam： Part A， 2022， 39（3）： 531-541.
[37]	LIU M， ZHANG L， JIANG S. A facile luminescence resonance energy transfer method for detecting cyano-containing pesticides in herbal medicines［J］. Microchem J， 2020， 152（1）： 104451.
[38]	SUN Z， LU J， ZHANG X， et al. Electrospun nanofibres containing Zn-MOF for electrochemiluminescent determination of fenpropathrin residues in fruit juices［J］. Food Chem， 2023， 405： 134950.

Methods	Model	Calibration set		Prediction set
Methods	Model	R_C	RMSEC/（mg·L^-1）	R_P	RMSEP/（mg·L^-1）
None	BP	0.995 9	0.067	0.990 2	0.102
	PLSR	0.800 7	0.426	0.807 4	0.419
	RFR	0.972 2	0.172	0.886 2	0.329
	SVR	0.991 1	0.126	0.874 6	0.359
S-G	BP	0.995 9	0.067	0.985 7	0.123
	PLSR	0.822 9	0.404	0.823 5	0.403
	RFR	0.983 8	0.115	0.929 5	0.244
	SVR	0.991 1	0.126	0.874 6	0.359
MC	BP	0.995 9	0.067	0.985 7	0.123
	PLSR	0.850 5	0.374	0.811 5	0.426
	RFR	0.983 6	0.132	0.937 2	0.249
	SVR	0.991 1	0.126	0.874 6	0.359
S-G+MC	BP	0.985 9	0.119	0.984 9	0.123
	PLSR	0.836 9	0.389	0.834 2	0.392
	RFR	0.988 3	0.112	0.931 3	0.259
	SVR	0.991 4	0.123	0.882 4	0.349

Methods	Model	Calibration set		Prediction set
Methods	Model	R_C	RMSEC/（mg·L^-1）	R_P	RMSEP/（mg·L^-1）
None	BP	0.995 9	0.067	0.990 2	0.102
	PLSR	0.800 7	0.426	0.807 4	0.419
	RFR	0.972 2	0.172	0.886 2	0.329
	SVR	0.991 1	0.126	0.874 6	0.359
S-G	BP	0.995 9	0.067	0.985 7	0.123
	PLSR	0.822 9	0.404	0.823 5	0.403
	RFR	0.983 8	0.115	0.929 5	0.244
	SVR	0.991 1	0.126	0.874 6	0.359
MC	BP	0.995 9	0.067	0.985 7	0.123
	PLSR	0.850 5	0.374	0.811 5	0.426
	RFR	0.983 6	0.132	0.937 2	0.249
	SVR	0.991 1	0.126	0.874 6	0.359
S-G+MC	BP	0.985 9	0.119	0.984 9	0.123
	PLSR	0.836 9	0.389	0.834 2	0.392
	RFR	0.988 3	0.112	0.931 3	0.259
	SVR	0.991 4	0.123	0.882 4	0.349

Actual concentration/（mg·L^-1）	Detected concentration/（mg·L^-1）		Recovery ratio/%		RSD/%
Actual concentration/（mg·L^-1）	Proposed method	HPLC-MS	Proposed method	HPLC-MS	Proposed method	HPLC-MS
0.08	0.076±0.005	0.080±0.001	95.0	100.0	6.6	1.3
0.6	0.580±0.030	0.589±0.017	96.7	98.2	5.2	2.9
0.8	0.853±0.055	0.829±0.022	106.6	103.6	6.4	2.7
1.5	1.638±0.024	1.466±0.036	109.2	97.7	1.5	2.5
2.5	2.262±0.170	2.507±0.021	90.5	100.3	7.5	0.8

Actual concentration/（mg·L^-1）	Detected concentration/（mg·L^-1）		Recovery ratio/%		RSD/%
Actual concentration/（mg·L^-1）	Proposed method	HPLC-MS	Proposed method	HPLC-MS	Proposed method	HPLC-MS
0.08	0.076±0.005	0.080±0.001	95.0	100.0	6.6	1.3
0.6	0.580±0.030	0.589±0.017	96.7	98.2	5.2	2.9
0.8	0.853±0.055	0.829±0.022	106.6	103.6	6.4	2.7
1.5	1.638±0.024	1.466±0.036	109.2	97.7	1.5	2.5
2.5	2.262±0.170	2.507±0.021	90.5	100.3	7.5	0.8

Methods	Pesticides	LOD/（μg·L^-1）	Ref.
Banded immunoassay	Fenpropathrin	62	［33］
Colorimetric sensor	Fenvalerate	4053	［34］
Enzyme linked immunosorbent assay	Cypermethrin	300	［35］
Lateral flow immunoassay	Cypermethrin	50	［36］
Fluorescence sensor	Fenpropathrin	0.24	［37］
Electrochemical sensor	Fenpropathrin	4.63×10^-3	［38］
SERS combined with BP	Cypermethrin	20	This work
